VSWR &Return Loss
| Frequency （MHz） | 700 | 960 | 1710 | 2170 | 2300 | 2690 |
| Return Loss | -20.43 | -20.7 | -18.71 | -8.41 | -9.91 | -10.89 |
| VSWR | 1.22 | 1.2 | 1.31 | 2.29 | 2 | 1.83 |
VSWR
Return Loss
| Frequency （MHz） | 700 | 820 | 960 | 1710 | 1950 | 2170 | 2300 | 2500 | 2690 |
| Efficiency(%) | 61.96 | 51.85 | 60.73 | 47.71 | 39.51 | 33.33 | 33.12 | 33.63 | 29.84 |
| Gain(dBi) | 2.15 | 2.18 | 2.73 | -0.83 | -0.13 | 0.32 | 0.8 | 2.59 | 2.88 |
