VSWR &Return Loss
| Frequency （MHz） | 824 | 960 | 1710 | 2170 | 2300 | 2690 |
| Return Loss | -9.61 | -20.42 | -6.16 | -12.36 | -9.31 | -7.11 |
| VSWR | 1.84 | 1.09 | 2.45 | 1.83 | 1.97 | 2.53 |
VSWR
Return Loss
| Frequency（MHz） | 820 | 880 | 960 | 1710 | 1850 | 2170 | 2300 | 2500 | 2690 |
| Efficiency(% ) | 55.56 | 57.66 | 57 | 27.41 | 31.48 | 65.58 | 68.84 | 54.66 | 59.22 |
| Gain .dBi | 1.64 | 1.97 | 2.18 | -0.15 | 2.55 | 3.75 | 4 | 2.82 | 2.55 |
