VSWR &Return Loss
| Frequency （MHz） | 820 | 960 | 1710 | 2170 | 2300 | 2690 |
| Return Loss | -21.46 | -12.7 | -14.81 | -21.33 | 18.51 | 25.52 |
| VSWR | 1.19 | 1.61 | 1.44 | 1.2 | 1.28 | 1.11 |
VSWR
Return Loss
| Frequency（MHz） | 820 | 900 | 960 | 1710 | 1930 | 2170 | 2300 | 2500 | 2690 |
| Efficiency(% ) | 47.17 | 44.31 | 46.15 | 34.74 | 33.43 | 32.12 | 36.49 | 33.75 | 31.36 |
| Gain .dBi | 0.57 | 0.8 | 0.7 | -1.52 | -1.58 | -2.38 | -2.16 | -2.58 | -2.41 |
