VSWR &Return Loss
| Frequency （MHz） | 820 | 960 | 1710 | 2170 | 2300 | 2690 |
| Return Loss | -3.55 | -6.44 | -11.17 | -13.82 | -19.96 | -11 |
| VSWR | 4.24 | 3.27 | 1.72 | 1.48 | 1.29 | 1.78 |
VSWR
Return Loss
| Frequency （MHz） | 820 | 890 | 960 | 1710 | 1950 | 2170 | 2300 | 2500 | 2690 |
| Efficiency(%) | 15.13 | 18.01 | 24.83 | 29.82 | 30.09 | 51.36 | 53.39 | 47.63 | 49.8 |
| Gain(dBi) | -3.67 | -2.73 | -1.33 | 0.03 | 0.91 | 1.15 | 0.83 | 0.24 | 0.6 |
