| Frequency(MHZ) | 824 | 960 | 1710 | 2170 | 2300 | 2690 |
| Return Loss | -17.47 | -11.79 | -17.83 | -17.51 | -22.73 | -11.76 |
| VSWR | 1.31 | 1.7 | 1.29 | 1.31 | 1.16 | 1.7 |
VSWR
Return Loss
| Frequency(MHZ) | 820 | 850 | 830 | 900 | 930 | 960 |
| Return Loss | 45.55 | 45.09 | 44.74 | 45.34 | 41.55 | 34.12 |
| VSWR | 0.1 | 0.02 | -0.07 | 0.06 | 0.14 | 0.27 |
| Frequency(MHZ) | 1710 | 1790 | 1890 | 1990 | 2090 | 2170 |
| Return Loss | 54.04 | 58.38 | 56.86 | 63.62 | 57.85 | 64.55 |
| VSWR | -0.05 | -0.21 | -0.33 | 1.16 | 0.38 | 0.93 |
| Frequency(MHZ) | 2300 | 2380 | 2460 | 2540 | 2620 | 2690 |
| Return Loss | 50.56 | 59.95 | 59.76 | 61.66 | 61.44 | 61.51 |
| VSWR | 0.03 | 1.07 | 0.78 | 0.7 | 0.22 | 0.29 |
