VSWR &Return Loss
| Frequency （MHz） | 698 | 960 | 1710 | 2170 | 2300 | 2690 | 3300 | 5000 | 915(R) |
| Return Loss | -7.27 | -5.29 | -9.1 | -18.66 | -28.15 | -23.58 | -12.43 | -9.32 | -5.03 |
| VSWR | 2.62 | 3.4 | 2.08 | 1.27 | 1.08 | 1.15 | 1.63 | 2.04 | 3.56 |
VSWR
Return Loss
| Frequency （MHz） | 820 | 960 | 1710 | 1950 | 2170 | 2300 | 2690 | 3300 | 4000 | 5000 |
| Efficiency(%) | 62.15 | 47.39 | 57.02 | 68.45 | 79.63 | 78.06 | 67.86 | 70.9 | 63.65 | 47.6 |
| Gain(dBi) | -0.3 | -0.73 | 0.07 | 1 | 2.54 | 4.1 | 4.76 | 5.44 | 3.37 | 2.86 |
